120E (F15) round bore, tapered extended nose
Features: Dead-length collet with round bore and tapered extended nose according to DIN 6343. Spring steel. hardened and ground.
- Length of extended nose: 15 mm
- Taper length: 9 mm
- Smooth round bore for all diameters
- Only the nominal size can be clamped.
Application: For use on the pick-up spindle or to avoid possible tool interferences
Clamping range mm |
increment mm |
Ø d mm |
Ø D mm |
L mm |
l mm |
Y mm |
α ° |
1.0 - 12.0 |
0.5 |
15.0 | 21.0 | 73.0 | 15.0 | 9.0 | 16° |
- Selected diameters available ex stock
- different diameters available on request
- grinding to intermediate diameters available on request.
