364E (W25) hexagon

364E (W25) hexagon

Features: Hexagonal draw-in collet according to DIN 6341. Spring steel, hardened and ground.

Application: For clamping workpieces in dividing heads, grinding machines or second-operation lathes. The draw-in collets are closed by being drawn back into the collet seating by means of a draw bar.

Technical data
hex size
mm max.		 increment
mm		 Ø d
mm		 Ø D
mm		 L
mm		 α
°

GA
4.0 - 17.0
1.0
 25.0 33.7 92.5 16° S25x1
  • Hexagonal profile with smooth bore
  • Only the nominal size can be clamped
  • Different hex sizes available on request
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      3 pieces
      Availability:
      Out of stock
      Availability:
      3 pieces
      Availability:
      3 pieces
      Availability:
      1 pieces
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      SKU A003.0364.1100
      82,50 € - 83,50 €
      Preis: 82,50 €
      82,50 € - 83,50 €
      Preis: Preis: 82,50 €
      plus VAT (if applicable), plus delivery charges
