366E square

Features: Square draw-in collet according to DIN 6341. Spring steel, hardened and ground.

Application: For clamping workpieces in dividing heads, grinding machines or second-operation lathes. The draw-in collets are closed by being drawn back into the collet seating by means of a draw bar.

Technical data
square size
mm max.
increment
mm
Ø d
mm
Ø D
mm
L
mm
α
°

G A

3.0 - 16.0
1.0
28.0 36.0 102.00 18° Tr27x1/20"
  • Square profile with smooth bore
  • Only the nominal size can be clamped
  • Selected sizes available ex stock
      Availability:
      Out of stock
      Availability:
      1 pieces
      Availability:
      Out of stock
      Availability:
      1 pieces
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      Out of stock
      Availability:
      2 pieces
      Availability:
      1 pieces
      Availability:
      1 pieces
      SKU A003.0366.2040
      Original price 85,25 € - Original price 90,00 €
      Original price
      Preis: 85,25 €
      85,25 € - 90,00 €
      Current price Preis: Preis: 85,25 €
      plus VAT (if applicable), plus delivery charges
